SAFT Shear Adhesion Failure Temperature Tester / ASTM D 3654 / ASTM
D 3645M / Shear Tester
Standard
D 3654/D 3645M(Test method for adhesive strength of
pressure-sensitive adhesive tape)
D 3715(Quality assurance regulation for pressure sensitive adhesive
tape)
D 4498(Standard test method for thermal interruption in shear of
hot-melt adhesive)
D 5750(Guide for width and length of pressure-sensitive tape)
PSTC-17(Test method for shear failure temperature of
pressure-sensitive adhesive tape)
PSTC-107(Pressure sensitive adhesive tape shear strength)
EN 1943(Adhesive tape - determination of static shear strength)
EN 10088/2, 2R(The specification demand of stainless steel plate)
ISO 29863(Adhesive tape - determination of static shear strength)
Afera 5012(Adhesive tape - determination of static shear strength)
Usage
It is suitable for measuring the ability of pressure-sensitive
adhesive tape to maintain adhesion under the condition of
continuous heating and a certain weight in parallel direction.
Shear strength is the ability of adhesive tape to withstand static
force when it is applied to the same plane as base material.
Overview of the test method
A strip of tape unrolled at a controlled speed is pasted onto a
standard steel plate. The steel plate is mounted vertically in an
adjustable heating furnace, then a standard weight is suspended at
the free end of the tape. The temperature of the heating furnace
increases steadily with the controlled speed, and then the shear
failure time is measured.
Technical Parameter
| Range of temperature control | Normal temperature～200℃ |
| Control method | Microcomputer P.L.D automatic temperature control calculation |
| Temperature analysis | 0.1℃ unit display |
| Control accuracy | ±0.3℃ |
| Heating rate | 0.5℃/min |
| Distribution accuracy | ±1%(200℃) |
| Weight attachment | 1kg, 6 groups |
| Electronic control | All the specimens fall off, then the buzzer rings (with switch),
and the heat is automatically cut off. |
| Manufacturing material | Interior: SUS#304 stainless steel plate. Exterior: the coating of the lacquer that bake. |
| Timer | Electronic LCD, store the time automatically, 99999.9 hours(or the
minute can be set) |
| Weight | 80kg |
| Size | 140×55×85cm |
| Power | 1φ, AC 220V/50Hz |
