400℃ Touch screen plastic melt flow index melt flow rate tester
Uses:
KJ-3092 melt flow rate testing instrument can be used for ABS,
polystyrene, polyethylene, polypropylene, polyamide, fiber resin,
acrylate, POM, fluorine plastic, polycarbonate and other plastic
materials, the melt flow rate (MFR) or the melt volume flow rate
(MVR) to be determined.
1. Product Description:
| Design Standard | GB/T3682-2000,ISO1133-97, ASTM1238 |
| Barrel parameters | Inner hole 9.55±0.025mm |
| Pistons parameters | Piston head: 9.475±0.015mm |
| Piston length | H=6.35±0.1mm |
| Paramters | Extrusion hole 1=2.095±0.005mm |
| Temperature parameter | With intelligent temperature control instrument, with four pairs of
significant temperature setting control, PID parameters can be
automatically set, precision up to ± 0.1 degree centigrade |
| Temperature rangeradius | 400degree centigrade |
| Temperature accuracyblade to jawand dust collector | ±0.2 degree centigrade |
| Display resolution | 0.1degree centigrade |
| Maximum comsuption | < 600W |
| Temperature recovery time | less 4 min. |
| Weight parameters are as follows: |
| Weight accuracy | ±0.5% |
| Basic configuration | 0.325 kg,1. kg,2.1 kg,3. kg,5. kg,10.0 kg 12. kg,21.6 kg |
| Position detection |
| Loop distance from up and down | 30mm |
| Control precision | ± 0.1mm |
| Test flow control |
| Times of cutting the material | 0~10 times |
| Material cutting interval | 0~999s(set reference Table 2) |
| Control flow reaches the set temperature without volatility |
| Barrel temperature time | 15 min. |
| Material be installed | 1 min |
| Material sample temperature recovery time | 4 min. |
| When binder set | 1min |
5. Certifications and letters patent
6. Packaging & Delivery
Packaging Details:Disposable Plastic Apron PE Film Making Machine
uses international standard package, big wooden cases
Delivery Time: 10-20 days after received deposit
7. Our services
1). Warranty time: All machines are guaranteed for one year free that we provide spare components except the wrong operation or
damaged by people on purpose.
2). Teaching services: Our engineers will teach your staff to operate the machine during
the period of installation and commissioning, and they will not
leave until your staff can operate it properly and normally when it
necessary.
3). Certificate services: Complying with our clients' request, we can provide related
certificates to clients freely
4). Maintenance services: If you have any questions or any malfunction happened,we will
reply you within 48 hours .
8. Contact us
If you want get more details ,or can not find out what are you
looking for,pls feel free to contact me,i will do my best for you.
