Elastomers 50N Mts Universal Testing Machines Panasonic Servo Motor
Design standard:
ASTM D903, GB/T2790/2791/2792, CNS11888, JIS K6854, PSTC7,ASTM C633
and etc.
KeJian tensile strength tester Uses:
Tensile Strength Testing Machine is designed for quick and reliable tensile, compression, bending,
shear, peel and fatigue cycling on metals, composites, alloys,
rigid plastics and films, elastomers, textiles, paper, board and
finished products.
Character:
1. Using the computer as the main control machine plus the special
testing software of our company can conduct all of testing
parameter, work state, collecting data&analysis, result display
and printing output.
2. Have steady performance, high accuracy, powerful software
function and easy operation.
3. Use the USA high-precision load cell.Machine accuracy is ±0.5%.
Accessories
1. Suitable Grips that meet customer sample need.
2. Special peeling tools for peel test in tape&film industry.
3. Software for test control,data acquisition and report.
4. English operation teach video.
5. Tabal,computer is selectable.
Technical parameter:
| Model | Computer Universal Tensile Testing Machine |
| Max load | 50N,100N,200N,500N, 1KN, 2KN (optional) |
| Accurate grade | 1 grade /0.5 grade |
| Effective measuring range | Force from 0.2% to 100% (1grade) / from 0.4% to 100% (0.5 grade) |
| Measuring accuracy | Tolerance ±1%/tolerance ±0.5% |
| Tester resolution | Max load 1/200000, and constant resolution |
| Load sensor | Basic configurationsensormax load:from four sensors to choose one |
| Effective tensile stroke | 800mm (can be widened according to customers requirement ) |
| Effective testing width | 300mm |
| Testing speed | From 0.001 to 500mm/min |
| Accruacy of displacement measurement | Tolerance: ±0.5% / tolerance: ±0.2% |
| Safety | Electronic-limit protection |
| Testing platform moving device | Fast /slow ( two speeds to control), can jog |
| Return Back | Manual or automatic operation, After the test, the moving iron
return to initial position with the highest speed by manual or
automatic operation |
| Overload protection | Overload 10%,automatic protection |
| Fixture | A set of tensile fixture |
| Machine size | 650*360*2100mm (L*W*H) |
| Power system | Panasonic AC Servo Motor + Driver + high-precision ball screw |
Software Functions:
1. Use windows working platform, set all parameter with dialog
forms and operate easy;
2. Using a single screen operation, do not need to change the
screen;
3. Have simplified Chinese, traditional Chinese and English three
languages,switch conveniently;
4. Plan test sheet mode freely;
5. Test data can be directly appeared in the screen;
6. Compare multiple curve data through translation or contrast
ways;
6. With many units of measurement, the metric system and british
system can switch;
7. Have automatic calibration function;
8. Have user-defined test method function
9. Have test data arithmetic analysis function
11. Have the function of automatic magnification, to achieve the
most appropriate size of graphics;
12. Can test tensile, compression, peel, fatigue and so on.
FAQ:
Why choose us?
1. Considerate Service Different countries plugs, manually change
the-voltage from 110V to 220V, insurance indicator.
2. Excellent after sale service:
1 YEAR warranty. If you have any problems during testing process,
we promise we will give you a reply with 24 hours and solution
provide within 3 working days. What you need to do is to send us
the controller.
3. Good Packaging:
Covered with air bubble film before put the machine into the wooden
case, which not only has good shock absorption, impact resistance,
heat sealing and also has the advantages of nontoxic, odorless,
moisture corrosion, good transparency etc.
