6.5KW 50×60×50 Inner Size Temperature Humidity Controlled Cabinets Humidity Testing Equipment

Ask Lasest Price
Brand Name :	KeJian
Model Number :	KJ-9033
Certification :	ISO,CE and etc.
Price :	Negotiate
Payment Terms :	L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
Supply Ability :	200 sets per month
Delivery Time :	In stock,3-7 working days after order confirmed

Add to Cart

Product Details
Company Profile

6.5KW 50×60×50 Inner Size Temperature Humidity Controlled Cabinets Humidity Testing Equipment

6.5KW 50×60×50 Inner Size Temperature Humidity Controlled Cabinets Humidity Testing Equipment

Chamber structure:

1. Outside bile uses high quality (t=1mm)SUS304 steel plate numerically-controlled machine tool to process,outside hull spray molding treatment,make chamber more bright and clean.

2. high density glass cellucotton,insulation thickness is 80mm.

3. Use long axis fan motor,heat and cold resistance,stainless steel siroco fan,to make sure strength convection and vertical diffusion cycle.

4. Between door and chamber,use double-deck thermostability sealing strips,to make sure testing area is airtight.

5. Use no-retroaction doorknob,easy operation.

6. In the bottom of chamber,use high quality stationary type PU running wheel.

7. Observing window uses multilayer hollow toughened glass.

Cooling system:

1. Compressor uses France TAIKANG whole sealing compressor.

2. Cooling system uses Unit or binary low temperature return circuit system.

3. US “AIGLE” drying and filtering device,Taiwan AIRMENDER oil separator,Italy Castel solenoid valve.

Product function:

Full spectrum xenon lamp

Various selective filtration system.

Water spray function.

Relative humidity controlling.

Testing chamber air temperature controlling system.

Irregular shape sample supporting structure.

Superior Xenon arc lamp.

Xenon lamp lifelong is decided by the illumination level of radiation intensity,the lifelong is about 1600 hours,it's easy to change the lamp.

Chamber Inner Size and Structure:

Inner size(cm):D×W×H	50×60×50
Power	6.5KW
Temperature range	Temperature range
Humidity range	65～98％R.H(adjustable)
Rain falling time	0～9999min (adjustable)
Rain falling period	1～240minutes,interval(break),adjustable
Spectral wavelength	290nm～800nm
Xenon lamp total power	1.8KW(lifetime:1600hours)
Time Controller	Imported programmable time computer integrated controller
Accuracy range	temperature ±0.1℃,humidity±1％R.H,indicate accuracy:temperature,±0.1℃,humidity,±1％R.H
Temperature Humidity Sensor	PTR Platinum Resistance,PT100Ω/MV
Heating system	autonomous system,nichrome electric heating heater
Humidification System	isolated type,SUS steel surface evaporative humidifier.
Blackboard temperature	thermometal blackboard thermometal.
Temperature controller	Imported microcomputer temperature humidity integration controller
cyclic system	low noise,air-condition type motor, multiple-pin Centrifugal rotor.
Outside chamber material	SUS304 stainless steel.
Inner chamber material	SUS304 stainless steel plate
Sample shelf material	SUS304 stainless steel plate
Doorframe heat insulation	good heat and cold resistance,aging Silicone rubber door and sealing strips.
Standard configuration	non-browning glass observing window 1pcs,xenon lamp 1pcs
Safeguard protection	leakage,short circuit,over temperature,short of water,motor overheating,over-current protection,Backup data for power fail
Voltage power	AC380V±10％ 50±0.5Hz 3 phase 5 lines
Using temperature	5℃～＋30℃≤85％R.H
Testing standards	GB/T2423.24-1995 GB/T16422.2 GB9344 GB/T1865-97 ASTM G 155-04a

RFQ:

Why choose us?

1. Considerate Service Different countries plugs, manually change the-voltage from 110V to 220V, insurance indicator.
2. Excellent after sale service:
1 YEAR warranty. If you have any problems during testing process, we promise we will give you a reply with 24 hours and solution provide within 3 working days. What you need to do is to send us the controller.
3. Good Packaging:
Covered with air bubble film before put the machine into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
