18.00KG Lab equipment Taber Abrasion Tester for Paint Coating With
250g, 500g, 1000g
Product description:
This machine is used for leather, cloth, coating, paper, floor
tile, plywood, glass, natural rubber wear-resistant test.
The main technical parameters:
Taber Abrasion tester
| Specimen Size: | ED:108mm ID:8mm ,3mm |
| Abrasion Wheel: | 2"(max.45mm), 1/2"(W) |
| Wheel Center Distance: | 63.5mm |
| Rotating Speed: | 60/72 rpm |
| Load: | 250g, 500g, 1000g |
| Counter: | LCD Touch screen, 0-999,999 Automatic shutdown |
| Wheel and Specimens disk center space: | 37~38mm |
| Machine Size: | (L*W*H)530*320*310mm + vacuum cleaner |
| Weight: | 18kg (Excluding vacuum cleaner) |
| Power: | 1, AC220V/50Hz |
| Wear index calculation formula: | Abrasion loss weight/test turnover number×1000 |
| Design criteria: | DIN-53754, 53799,53109,52347, TAPPI-T476, ASTM-D1044,D3884,
ISO-5470 |
| Specimen Size: | ED:108mm ID:8mm ,3mm |
| Abrasion Wheel: | 2"(max.45mm), 1/2"(W) |
| Wheel Center Distance: | 63.5mm |
Accessories:
- One vacuum cleaner machine
- One H10 wheel
- One box of abrasive papers for recondition the wheel
- Load 250,500 and 1000g
Taber Wear Rotary Abrasion Tester and wear testing machine can be
replaced by wheel and weight,
which apply to the abrasion resistance performance test on fabric,
cardboard, paint, leather, tile, glass and natural rubber,
method is simple and easy to operate,which has been widely used in
various industry's testing laboratory.
Abrasion tests, the material is standard wheel friction after a
certain number of turns,
evaluate its abrasion resistance material weightlessness rate by
calculation.
Abrasion wheel after pre grinding standard method, test results can
reach very high consistency.
Core advantages
Simple operation, display real-time speed, the speed control can be
achieved 30-75rpm adjustment,
wearing can be preset number of turns. Arm can match with balance
weights, accurate weight balance abrasion arm,
to realize the ASTM standard which requires 125 g pressure
requirements
Vacuuming mouth height is adjustable, and adapt to different
thickness materials, efficient removal of debris, improve test
accuracy
Brand motor, mute, low noise, smooth operation
Applicable Standards
ISO 9352, ISO 5470, ISO 7784, ASTM D1044, ASTM D3884, ASTM D4060,
GB/T 5137.1, QB/T 2726, DIN 53109
Basic configuration
| G270 | Taber Abrasion Resistance Tester |
| (250g,500g,1000g)
Weight × 1 set (250g, 500g, 1000g each one pairs) |
Accessories
| 27001 | 1 pair of 125g Balance weights and fixed screw |
| 27002-1 | 1 pair of Import original abrasion wheel CS-10×1 |
| 27002-2 | 1 pair of Import original abrasion wheel H-18×1 |
| 27003 | Import the original decoration sandpaper (grinding disc) S - 11 x 1
package (100 pieces/package) |
| 27004 | Import original sample sticker S - 36 (50 / package) |
| 27005 | Diamond wheel polisher (friction wheel polishing Taber) |
| XC001 | One set of the vacuum cleaner |
