LCD Display Tension Tensile Testing Machine With Paint-Coated
Aluminium Blanking Plate
Design standard:
ASTM D903, GB/T2790/2791/2792, CNS11888, JIS K6854, PSTC7,ASTM C633
and etc.
Uses:
Single Column Compression Testing Machine is designed specially for the adhesive industry. Used to testing
peeling strength with different methods. It can perform the
180&90 degree, T-shape peeling test and
tensile,shearing&spliting strength test with different clamps.
KeJian tensile strength tester Uses:
Tensile strength tester is designed for quick and reliable tensile, compression, bending,
shear, peel and fatigue cycling on metals, composites, alloys,
rigid plastics and films, elastomers, textiles, paper, board and
finished products.
1. APPLICATION: it is used for testing tension power of both metallic and
non-metallic materials such as rubber, plastic, textile,
waterproofing materials, wire and cable, safe belt, leather belt
composite materials, net wire, steel, stainless steel, metal rod,
plates and other materials. by using suit accessories, it can also
perform compression, bending and flexure test.
2. SPECIFICATIONS:
| Models | STLLJ-1 |
| Maximum test load | 10kN |
| Resolution grade | | 1 grade |
| Load parameters | Force measurement range | 0.4%-100%FS(full-scale) |
| Force display deviation | Within ±1% of display value |
| Test force resolution | ±1/300000 of maximum load |
| Large deformation parameters | Large deformation test range | 10-800mm |
| Large deformation display deviation | Within ±1% of display value |
| Large deformation measurement resolution | 0.008mm |
| Displacement parameters | Displacement display deviation | Within ±0.2% of display value |
| Displacement resolution | 0.027μm |
| Control parameters | Force control rate adjustment range | 0.005-5%FS/s |
| Deformation rate control range | 0.005-5%FS/s |
| Test shelf rate control accuracy | Within ±0.2% of set value |
| Constant force, constant deformation, constant displacement control
range | 0.5%-100%FS |
| Constant force, constant deformation, constant displacement control
accuracy | Within ±1% of set value when set value≥10%FS |
| Within ±1% of set value when set value<10%FS |
| Test shelf rate control | 0.001~500mm/min |
| Host machine parameters | Outside dimension | 710mm×426mm×1570mm |
| Effective tensile space (including tensile fixture) | 650mm |
| Effective compression space (including compression fixture) | 800mm |
| Maximum beam movement | 900mm |
| Effective test width | 410mm |
| Power | 1 phase, 220V/50Hz,±10%, 0.4KW |
| Machine weight | 180Kg |
